1000P Technical Specifications | |
| Gross Capacity (Lt.) | 1140 |
| Useful Capacity (lt.) | 1045 |
| Internal dimensions (wxdxh) (mm) | 900x668x1800 |
| External dimensions (wxdxh) (mm) | 1000x849x2200 |
| External dimensions With Package (wxdxh) (mm) | 1020x869x2342 |
| Product Foot Print Area (Shelves) (m²) | 0,548 |
| Net weight (Kg) | 208 |
| Gross Weight With Package (Kg) | 222 |
| Facing (width) (330ml – Ø 66,3 mm) | 13 |
| Facing (depth) (330ml – Ø 66,3 mm) | 9 |
| Facing (width) (330ml – Ø 57 mm) | 15 |
| Facing (depth) (330ml – Ø 57 mm) | 10 |
| Product Display Area (m²) | 0,831 |
| Can (330ml – Ø 66,3 mm) Loading | 345+1 pallet (768) |
| Can (330ml – Ø 57 mm) Loading | 298+1 pallet (840) |
| Bottle 500ml. Loading | 116+1 pallet (432) |
| Number of Shelves | 1 |
| Insulation Thickness (mm) | 50 |
| Temperature Range °C | 4 / +12 °C |
| Refrigerant (Gas) | R134a/R600a/R290a |
| Condition | B/C (R134a/R600a) |
| Voltage | 220-240 / 50 V/Hz |
| Loading Container 20″ | 12 |
| Loading Container 40″ | 28 |
| Loading Container 40″ HC | 28 |
| Loading Truck 13,6 Mt | 30 |
| Gross Capacity (Lt.) | 821 |
| Useful Capacity (lt.) | 730 |
| Internal dimensions (wxdxh) (mm) | 900x668x1372,5 |
| External dimensions (wxdxh) (mm) | 1000×829,5×1773 |
| External dimensions With Package (wxdxh) (mm) | 1015x850x1910 |
| Product Foot Print Area (Shelves) (m²) | NA |
| Net weight (Kg) | |
| Gross Weight With Package (Kg) | |
| Facing (width) (330ml – Ø 66,3 mm) | 13 |
| Facing (depth) (330ml – Ø 66,3 mm) | 9 |
| Facing (width) (330ml – Ø 57 mm) | 15 |
| Facing (depth) (330ml – Ø 57 mm) | 10 |
| Product Display Area (m²) | 0,830 |
| Can (330ml – Ø 66,3 mm) Loading | 1 pallet (768) |
| Can (330ml – Ø 57 mm) Loading | 1 pallet (840) |
| Bottle 500ml. Loading | 1 pallet (432) |
| Number of Shelves | 0 |
| Insulation Thickness (mm) | 50 |
| Temperature Range °C | 4 / +12 °C |
| Refrigerant (Gas) | R134a/R600a/R290a |
| Condition | B/C (R134a/R600a) |
| Voltage | 220-240 / 50 V/Hz |
| Loading Container 20″ | 12 |
| Loading Container 40″ | 28 |
| Loading Container 40″ HC | 28 |
| Loading Truck 13,6 Mt | 30 |
